ECS GF8100VM-M5 User Manual

15
Installing the Motherboard
Type Size Vendor Module Name
Infineon HYS64T325001HU-3-A
256 MB
Ramaxel 5NB31 D9DCG
A-DATA AD29608A88-3EG
VALUESELECT 32M8CEC
64M8CFE PS1000545 Cors air
Cors ai r K4T51083QC
GEIL GL2L64M088BA18W
Ramaxel 5LB31 D9DCL
Samsung K4T51083QC
SyncMAX 04400WB01 R050008A
Transcend JetRam J12Q3AB-6
512 MB
Twinmos TMM6208G8M30B
Elpida AM4B5708GEWS7E-0637F
Apacer
AM4B5708GQJS7E0631F
Corsair 64M8CFEG QIB0900721
GEIL GL2L64M088BA30P
HYB18T512800BF3S
1 GB
Infineon
Aeneon AET93E30RB-0650 1GB
Apacer AM4B5808CQJS7E 0749B
Hynix HYMP125U64AP8-Y5 AB-A 0623
DD R 2 6 67
2 GB
LeadMax LeadMax LD5PS1G831
Corsair CM2X1024-6400PRO
Infineon HYS64T64020HU-2.5-A
Infinity 04751208CZ5U2D
512 MB
Sync MAX U538H8G090HL
A-DATA VD29608A8D -25EG-E0722
GEIL GL2L64M088BA18H
Infinity 04701G16CZ5U 2G
Transcend TQ123PGF8T0709
1 GB
UMAX U2S12D30TP-8E
A-DATA AD20908A8A-25EG 20818
Apacer AM4B5808CQJS8E 0747D
Corsair CM2X2048-6400C5
GEIL Geil platinum ver sion
DDR2 800
2 GB
Samsung M378T5663QZ3-CF7
Memory
Recommend Volt
MT16HTF25664AY-1GAE1 1.9 V
Module Name
Mic r on
Type Size Vendor
1 GB
MT8HTF12864AY-1GAE1 1.9 V
DDR2 1066
2 GB
Mic r on
DDR2 1066 is supported when using socket AM2+ CPU.

ECS GF8100VM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	4
Power fan connector	Yes
Number of SATA connectors	6
Controller interface type	NVIDIA MCP78V
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
Maximum graphics card memory	512 MB
RAID levels	0, 1
