H110M-C3V/H110M-C3D
USER MANUAL
Chapter 1
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the H110M-C3V/H110M-C3D motherboard. This motherboard
is a high performance, enhanced function motherboard designed to support the
LGA1151 socket for
Intel
®
Skylake processor.
This motherboard is based on Intel
®
H110 Express Chipset for best desktop platform
solution. It supports up to 32 GB
of system memory with dual channel DDR3L 1600
MHz. One PCI Express x16 Gen3 slot is supported, intended for Graphics Interface. In
addition, one PCI Express x1 Gen2 slot is for extending usage.
It integrates USB 2.0 and USB 3.0 interface, supporting up to six USB 2.0 ports (two
USB 2.0 ports at rear panel and two USB 2.0 headers support additional four USB 2.0
ports) and four USB 3.0 ports (two USB 3.0 ports at the rear panel and one USB 3.0
header supports additional two USB 3.0 ports).
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including one PS/2 mouse and PS/2 keyboard connector, one DVI port (or one HDMI
port), one VGA port, two USB 3.0 ports, two USB 2.0 ports, one RJ45 LAN connector,
and audio jacks for line-in, line-out and microphone.
In addition, this motherboard supports four SATA 6Gb/s connectors for expansion.
Your motherboard package ships with the following items:
Package Contents
H110M-C3V/H110M-C3D Motherboard
User Manual
DVD
I/O Shield
2 SATA 6G Cables
The package contents above are for reference only, please take the actual package items as
standard.
