ECS H110M-C3V User Manual

Chapter 3
H110M-C3V/H110M-C3D USER MANUAL
52
+/- : Change Opt.
Enter/Dbl Click : Select

: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit

Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking
Configuration
Tweak
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
Tweak Menu
Intel(R) Core(TM) i5-6400T CPU @ 2.20GHz
Processor Speed 2500 MHz
Memory Frequency 1067 MHz
Total Memory 1024 MB
CPU OverClocking Configuration
Memory Configuration
Spread Spectrum Auto
EIST (Enabled)
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep
Technology).
Turbo Boost (Enabled)
This item allows you to enable or disable turbo boost.
Main Advanced Chipset Tweak Security Boot Exit
Enhanced Intel SpeedStep
Technology
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
EIST Enabled
Turbo Boost Enabled
Power Limit 3 Settings
Power Limit 4 Settings
Performance Mode Boost
TDP Lock Disabled
Core Ratio 22
Core 1 Ratio Limit 28
Core 2 Ratio Limit 27
Core 3 Ratio Limit 25
Core 4 Ratio Limit 25
 CPU OverClocking Configuration
Scroll to this item to view the following screen:
