ECS H61H2-M2 User Manual

34
Using BIOS
Inter(R) Core(TM) i3-2100 CPU @ 3.10GHz
This is display-only field and diaplays the information of the CPU installed in your
computer.
EMT64 (Supported)
This item shows the computer supports EMT64.
Processor Speed (3100MHz)
This item shows the current processor speed.
Processor Stepping (206a7)
This item shows the processor stepping version.
Microcode Revision (25)
This item shows the Microcode version.
Processor Cores (2)
This item shows the core number of the processor.
Intel HT Technology (Supported)
This item shows that your computer supports Intel HT technology or not.
Hyper-threading (Enabled)
This item is only available when the chipset supports Hyper-threading and you are
using a Hyper-threading CPU.
Excute Disable Bit (Enabled)
This item allows the processor to classify areas in memory by where application code
can execute and where it cannot. When a malicious worm attempts to insert code in
the buffer, the processor disables code execution, preventing damage or worm propa-
gation. Replacing older computers with Execute Disable Bit enabled systems can halt
worm attacks, reducing the need for virus related repair.
Intel Virtualization Technology (Disabled)
When disabled, a VMM cannot utilize the additional hardware capabilities provided
by Vandor Pool Technology.
CPU C3 Report (Disabled)
This item is used to enable or disable CPU C3 (ACPI C2) report to OS.
Press <Esc> to return to the Advanced Menu page.
Limit CPUID Maximum (Disabled)
Use this item to enable or disable the maximum CPUID value limit. When supports
Prescott and LGA775 CPUs, enables this to prevent the system from “rebooting”
when trying to install Windows NT 4.0.
Intel VT-x Technology (Supported)
This item shows that your computer supports Intel VT-x technology or not.
Active Processor Cores (All)
Use this item to control the active processor cores.
CPU C6 Report (Disabled)
This item is used to enable or disable CPU C6 (ACPI C3) report to OS.
Enhanced Halt (C1E) (Enabled)
This item enables or disables enhanced halt.

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
