ECS H61H2-M2 User Manual

50
Using BIOS
This page enables you to set the keyboard NumLock state.
Boot Menu
Boot Configuration
This item shows the information of the boot configuration.
Bootup NumLock State (On)
This item determines if the NumLock key is active or inactive at system start-up
time.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Select the keyboard NumLock
state
Main Advanced Chipset M.I.B III Boot Security Save & Exit
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Boot Configuration
Bootup NumLock State [On]
Set Boot Priority
1st Boot [Hard Disk]
2nd Boot [CD/DVD]
3rd Boot [USB/Floppy]
4th Boot [USB CD/DVD]
5th Boot [USB Hard Disk]
6th Boot [USB Flash]
7th Boot [Network]
8th Boot [UEFI]
Hard Disk Drive Priorities [Press Enter]
CD/DVD ROM Drive Priorities [Press Enter]
USB/Floppy Drive Priorities [Press Enter]
USB CD/DVD ROM Drive Priorities [Press Enter]
USB HardDisk Drive Priorities [Press Enter]
USB Flash Drive Priorities [Press Enter]
Network Device Priorities [Press Enter]
UEFI Boot Drive Priorities [Press Enter]
f
f
f
f
f
f
f
f
Hard Disk Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing hard disk drives.
CD/DVD ROM Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing CD/DVD ROM drives.
USB/Floppy Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB/floppy drives.
USB CD/DVD ROM Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB CD/DVD ROM drives.
1st/2nd/3rd/4th/5th/6th/7ht/8th Boot
These items set the system boot order.

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
