ECS H61H2-M2 User Manual

51
Using BIOS
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
This page enables you to set setup administrator and password.
Security Menu
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Set Administrator Password
Administrator Password Status Not Install
User Password Status Not Install
Administrator Password
Main Advanced Chipset M.I.B III Boot
Security Save & Exit
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
USB HardDisk Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB harddisk drives.
USB Flash Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB flash drives.
Network Device Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing network devices.
UEFI Boot Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing UEFI Boot drives.
Administrator Password Status (Not Install)
This item shows administrator password installed or not.
User Password Status (Not Install)
This item shows user password installed or not.
Administrator Password
Press <Enter> to setup administrator password.

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
