ECS H61H2-M2 User Manual

4
Introducing the Motherboard
• LGA1155 socket for the latest Intel
®
Core
TM
Family/Pentium
®
/
Celeron
®
processors
• Supports “Hyper-Threading” technology CPU
• DMI 5.0GT/s
CPU
Specifications
• AMI BIOS with 32Mb SPI Flash ROM
• Support Multi-language BIOS Utility
• Support ECS M.I.B III Utility
Form Factor • Micro ATX Size, 225mm x 180mm
System BIOS
• Support eBLU/eDLU/eSF
AP support
• Intel
®
H61 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports 1333/1066 DDR3 SDRAM
• 1 x PCI Express x16 slot
• 2 x PCI Express x1 slots
• Supported by Intel
®
H61 Express Chipset
-4 x Serial ATA 3.0 Gb/s devices
• VIA VT1705 6-Ch HD audio CODEC
• Compliant with HD audio specification
• 4 x USB 2.0 ports
• 1 x D-sub (VGA)
• 1 x DVI port (optional)
• 1 x HDMI port (optional)
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
• 1 x PS/2 keyboard & PS/2 mouse connectors
Memory
Expansion
Slots
Storage
LAN
Rear Panel I/O
• Atheros AR8152-B 10/100 Lan (Optional)
• Atheros AR8152-B Gigabit Fast Ethernet Controller (Optional)
Audio
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3.0 Gb/s connectors
• 1 x COM header
• 1 x Case Open header
• 1 x SPDIF out header
• 1 x TPM header
• 1 x ME_UNLOCK header
• 1 x Speaker header
• 1 x Clear CMOS header
Internal I/O
Connectors &
Headers

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
