Installing the Motherboard
A
TX12V
:
A
TX 12V Power Connector
P
in
Signal Name
4
+12V
3
+12V
2
Ground
1
Ground
SPK: Internal speaker
P
in
Signal Name
1
VCC
2
Key
3
GND
4
Signal
PWR_F
AN: Power Cooling F
AN Power Connector
1
GND
System Ground
3
Sense
Sensor
P
in
Signal Name
Function
2
+12V
Power +12V
29
31
Table of Contents
Default Chapter
2
About the Manual
2
Canadian Department of Communications
2
Declaration of Conformity
2
Table of Contents
3
Chapter 1 Introducing the Motherboard
5
Introduction
5
Feature
6
BIOS Firmware
7
Specifications
8
Motherboard Components
10
Chapter 2 Installing the Motherboard
13
Safety Precautions
13
Choosing a Computer Case
13
Installing the Motherboard in a Case
13
Checking Jumper Settings
14
Setting Jumpers
14
Checking Jumper Settings
15
Jumper Settings
15
Installing Hardware
16
Installing the Processor
16
Cpu Installation Procedure
17
Installing Memory Modules
18
Expansion Slots
20
Connecting Optional Devices
22
Installing a SATA Hard Drive
26
Connecting I/O Devices
27
Connecting Case Components
28
Front Panel Header
31
Hard Drive Activity LED
31
Power/Sleep/Message Waiting LED
31
Chapter 3 Using BIOS
33
About the Setup Utility
33
The Standard Configuration
33
Entering the Setup Utilities
33
Resetting the Default CMOS Values
34
Using BIOS
34
BIOS Navigation Key
35
Main Menu
35
Advanced Menu
36
Lan Configuration
37
Pc Health Status
38
Smart Fan Function
38
Power Management Setup
40
Acpi Configuration
41
Cpu Configuration
41
Sata Configuration
43
Usb Configuration
44
Serial Port 0 Configuration
45
Super Io Configuration
45
Trusted Computing
47
Chipset Menu
48
M.I.B.III(MB Intelligent Bios III) Menu
55
Boot Menu
60
Security Menu
61
Save & Exit Menu
62
Updating the BIOS
64
Chapter 4 Using the Motherboard Software
65
About the Software DVD-ROM/CD-ROM
65
Auto-Installing under Windows Xp/Vista/7
65
Running Setup
66
Manual Installation
68
Utility Software Reference
68
Chapter 5 Setting up Ejiffy
69
Introduction
69
Installation and BIOS Setup
70
Entering Ejiffy
73
Features Icons
74
Usage FAQ
75
Chapter 6 Trouble Shooting
81
Start up Problems During Assembly
81
Start up Problems after Prolong Use
82
Maintenance and Care Tips
82
Basic Troubleshooting Flowchart
83
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the ECS H61H2-M5 and is the answer not in the manual?
Ask a question
ECS H61H2-M5 Specifications
General
Brand
ECS
Model
H61H2-M5
Category
Motherboard
Language
English
