Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paeameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
CPU Fan Speed : 2974 RPM
System Fan Speed : 0RPM
Power Fan Speed : 0RPM
CPU Vcore : 1.248V
IMC Voltage : 1.056V
VDIMM : 1.536V
PC Health Status
Smart Fan Function
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
-=- PECI Mode -=-
Offset to TCC Activation Temp : -52
CPU/System/Power SMART FAN Control (Enabled)
This item allows you to enable/disable the control of the CPU/System/Power fan
speed by changing the fan voltage.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
SMART Fan Mode [Normal]
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (-) 23
System SMART Fan Control [Enabled]
SMART Fan Mode [Normal]
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unite
System Fan Full Speed Offset (-) 23
Power SMART Fan Control [Enabled]
SMART Fan Mode [Normal]
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unite
Power Fan Full Speed Offset (-) 23
Scroll to this item and press <Enter> to view the following screen:
