4
Introducing the Motherboard
• Intel
®
H61 Chipset
• LGA1155 socket for 2
nd
Generation Intel
®
Core
TM
Family/
Pentium
®
/Celeron
®
processors
• Supports “Hyper-Threading” technology CPU
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports 1333/1066 DDR3 SDRAM
• 1 x PCI Express x16 Gen2 slot
• 3 x PCI Express x1 Gen2 slots
• Supported by Intel
®
H61 Express Chipset
-4 x Serial ATA 3.0 Gb/s Host Controllers
• Realtek ALC662 6-Ch HD audio CODEC
• Compliant with HD audio specification
• 6 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x DVI port (HDMI port optional)
• 1 x VGA port
• 1 x RJ45 LAN connector
• 1 x PS/2 keyboard & PS/2 mouse combo connector
• 1 x Audio port (Line in, microphone in, 6-ch line out)
Chipset
Memory
Expansion
Slots
Storage
LAN
CPU
Specifications
Rear Panel I/O
• Realteck RTL 8111E Gigabit Lan (Co-lay RTL8105E Lan )
Audio
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 1 x 3-pin PWR_FAN connector
• 4 x Serial SATA 3.0 Gb/s connectors
• 1 x Front panel switch/LED header
• 1 x Front panel audio header
• 2 x USB 2.0 headers support additional four USB 2.0 ports
(F_USB1 supports optional EZ charger)
• 1 x Chassis intrusion header
• 1 x COM header
• 1 x SPDIF out header
• 1 x Speaker header
• 1 x Clear CMOS header
• 1 x LPT header
• 1 x TPM header
Internal I/O
Connectors &
Headers
To Next Page
