1
Introducing the Motherboard
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the H61H2-M5 motherboard. This motherboard is a high
performance, enhanced function motherboard designed to support the LGA1155
socket for
2
nd
Generation Intel
®
Core
TM
Family/Pentium
®
/Celeron
®
processors for
high-end business or personal desktop markets.
This motherboard is based on Intel
®
H61 Chipset for best desktop platform solution.
H61 is a single-chip, highly integrated, high performance Hyper-Threading periph-
eral controller, unmatched by any other single chip-device controller. This
motherboard supports up to 8 GB
of system memory with dual channel DDR3 1333/
1066 SDRAM. High resolution graphics via PCI Express x16 slot, intended for
Graphics Interface, is fully compliant to the PCI Express Base Specification revision
2.0. Three PCI Express slots are supported. It implements an EHCI (Enhanced Host
Controller Interface) compliant interface that provides ten USB 2.0 ports (six USB
2.0 ports at the back panel and two USB 2.0 headers support additional four USB 2.0
ports). The gray USB 2.0 header provides optional EZ charger technology, please
reference chapter 2 parts of Front Panel USB headers to check the detail informa-
tion. In addition, H61H2-M5 implements extra USB 3.0 chip which provides two
USB 3.0 ports* at rear I/O with blue connectors also.
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including PS/2 mouse and PS/2 keyboard combo connector, one DVI(HDMI port
optional) port, one D_sub (VGA) port, one Lan port, six USB 2.0 ports, two USB 3.0
ports, and audio jacks for microphone, line-in and line-out.
In addition, this motherboard supports four SATA 3Gb/s connectors for expansion.
*The USB 3.0 connectors are optimized for SuperSpeed USB 3.0 devices,
aslo are fully backwards-compatible with Hi-Speed USB 2.0 devices.
