Chapter 3
H87H3-TI USER MANUAL
47
The chipset menu items allow you to change the settings for the North Bridge
chipset, South Bridge chipset and other system.
Chipset Menu
System Agent (SA)
Parameters
Main Advanced Chipset Tweak Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
/Click: Select Item
IGD Memory (64M)
This item shows the information of the IGD (Internal Graphics Device) memory.
DVMT Memory (256M)
When set to Fixed Mode, the graphics driver will reserve a fixed position of the sys-
tem memory as graphics memory, according to system and graphics requirements.
Select DVMT 5.0
Pre-Allocated (Fixed)
Graphics Memory size used
by the Internal Graphics
Device.
Main Advanced Chipset Tweak Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
/Click: Select Item
System Agent Configuration
IGD Memory 64M
DVMT Memory 256M
CPU SA Audio Device Enabled
System Agent Configuration
PCH Configuration
ME Configuration
Scroll to this item and press <Enter> and view the following screen:
System Agent Configuration
Press <Esc> to return to the Chipset Menu page.
CPU SA Audio Device (Enabled)
This item allows you to enable or disable the CPU SA Audio device.
