Chapter 1
2
H87H3-TI USER MANUAL
Specifications
• Dual-channel DDR3 memory architecture
• 2 x 204-pin DDR3 SO-DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333 MHz DDR3 SDRAM
Memory
• 2 x mini PCI Express slots
- mini PCIe1 (full-card) supports extension cards with SATA
signal, USB signal and PCIe signal.
- mini PCIe2 (half-card) supports extension cards with PCIe
signal.
• Supported by Intel
®
H87 Express Chipset
- 2 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
• 1 x 19V DC_IN port
• 1 x HDMI in port (For All-In-One Specification)
• 1 x Display port (DP)
• 4 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (1 x line-out, 1 x Microphone)
• 1 x HDMI out port
Rear Panel I/O
LAN
• Realtek RTL8111G
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Realtek ALC662
- 2 Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio
CPU
• Intel
®
H87 Chipset
• Supports Intel
®
Smart Response Technology
• Supports Intel
®
Smart Connect Technology
• Supports Intel
®
Rapid Start Technology
Chipset
• LGA1150 socket for
Intel
®
4
th
Generation Core
TM
Family
processors
• VRD 12.5
• 1 x 4-pin CPU_FAN connector with smart fan function
• 1 x 4-pin SYS_FAN connector with smart fan function
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 2 x 10-pin USB 2.0 headers support additional four USB 2.0
ports
- 1 x 10-pin USB 2.0 header (black) supports card reader and
camera or other USB 2.0 device
- 1 x 10-pin USB 2.0 header (gray) supports additional two USB
2.0 devices
• 1 x 5-pin USB 2.0 header supports additional one USB 2.0 port
• 2 x Serial SATA 6Gb/s connectors
• 1 x Case open header
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
Internal I/O
Connectors &
Headers
