ECS H87H3-TI User Manual

Chapter 3
H87H3-TI USER MANUAL
50
Tweak Menu
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
Main Advanced Chipset Tweak Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking
Configuration
Tweak
Genuine Intel(R) CPU 0000 @ 2.80GHz
Processor Speed 2800 MHz
Memory Frequency 1067 Mhz
Total Memory 2048 MB (DDR3)
CPU Ratio (28)
This item allows users to control non turbo CPU ratio.
Package Current Lock (Disabled)
This item allows users to enable or disable the package current lock.
IA Core Current (Maximum)
This item allows you to set IA Core Current.
Main Advanced Chipset Tweak Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking Configuration
Scroll to this item and press <Enter> to view the following screen:
Package Current Lock
CPU OverClocking Configuration
North Bridge Configuration
Spread Spectrum Enabled
CPU Ratio 28
Package Current Lock Disabled
IA Core Current Maximum
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
Runtime Turbo Enable Disabled
Internal PLL Overvoltage Disabled
Boot Performance Mode Disabled
Package TDP Lock Enable Max Non-Turbo Perfor...
Long Duration Power Limit Override Maximum
Power Limit 1 Time(Second) 8
Power Limit 2 Switch Enabled
Short Duration Power Limit Override Maximum
1 Core Ratio Limit 32
2 Core Ratio Limit 31
3 Core Ratio Limt 30
4 Core Ratio Limit 30
Disabled OverClocking Lock Enabled
