Table of Mainboard Components
Label Component
AGP1 Accelerated Graphics Port
ATX1 Standard 20-pin ATX power connector
AUDIO1 Front panel MIC/Speaker Out header
BAT1 Three volt realtime clock battery
CD1 Primary CD-in connector
CD2 Secondary CD-in connector
CNR1 Communications and Networking Riser slot
CPUFAN1 Cooling fan for CPU
CPU Socket Socket 462 for AMD Athlon/Duron CPUs
DDR1 ~ DDR2 Two 184-pin DDR memory modules
FDC Floppy disk drive connector
IDE1 Primary IDE channel
IDE2 Secondary IDE channel
J1 Onboard LAN LED Connector
JP2 Clear CMOS Memory Jumper
JP3 CPU Clock Selector
JP5 Keyboard Power On Selector
PANEL1 Panel connector for case switches and LEDs
PCI1 ~ PCI2 Two 32-bit add-on card slots
SDR1 ~ SDR2 Two 168-pin SDRAM memory modules
SIR1 Serial Infrared cable header
SPK1 Internal speaker connector
SYSFAN1 System Fan connector
USB2 ~ USB3 Connectors for front panel USB ports
WOL1 Wake On LAN header
This concludes Chapter 1. The next chapter explains how to install the main-
board.
