Installing Add-on Cards
This mainboard has two 32-bit PCI (Peripheral Components Interconnect)
expansion slots, one AGP slot, and one Communications and Networking
Riser (CNR) slot.
AGP Slot The AGP slot is used to install a graphics adapter that supports the
4xAGP specification and has a 4xAGP edge connector.
Note: The above layout is for reference only. The AGP slot
may be different from your mainboard. Please refer to
actual shipment.
PCI Slots PCI slots are used to install expansion cards that have the 32-bit PCI
interface.
CNR Slot This slot is used to insert CNR cards with Modem and Audio func-
tionality.
Note: Before installing an add-on card, check the documentation for the card
carefully. If the card is not Plug and Play, you may have to manually con-
figure the card before installation.
19
