CPU PnP Setup Page
This page lets you manually configure the mainboard for the CPU. The system
will automatically detect the kind of CPU that you have installed and make the
appropriate adjustments to the items on this page.
AMIBIOS SETUP – CPU PnP SETUP
(C) 2000 American Megatrends, Inc. All Rights Reserved
-=≡CPU PnP Type≡=-
CPU Brand AMD K7
CPU Type Duron
CPU Frequency Auto
SDRAM Frequency Auto
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load Optimal values
F7 : Load Best performance values
CPU Brand/Type (AMD K7/Duron)
These items show brand and type of the CPU installed in your system.
CPU / SDRAM Frequency
These items decide frequency of the CPU/SDRAM installed in your system.
Hardware Monitor Page
This page sets some of the parameters for the hardware monitoring function
of this mainboard.
AMIBIOS SETUP – HARDWARE MONITOR
(C) 2000 American Megatrends, Inc. All Rights Reserved
*** System Hardware ***
Vcore 1.616 V
Vcc 2.5V 2.496 V
Vcc 3.3V 3.392 V
Vcc 5 V 4.945 V
+12V 12.032V
-12V - 12.000V
SB5V 5.026 V
VBAT 3.472 V
SYSTEM Fan Speed 0 RPM
CPU Fan Speed 1318 RPM
SYSTEM Temperature 39°C/102°F
CPU Temperature 32°C/ 89°F
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load Optimal values
F7 : Load Best performance values
System / CPU Temperature
These items display CPU and system temperature measurement.
FANs & Voltage Measurements
These items indicate cooling fan speeds in RPM and the various system volt-
