you select a specific address, the resources are assigned to the IR port, and
you can use the five items below to determine the operation of the IR port
Onboard Parallel Port (378h)
This item enables or disables the onboard LPT1 parallel port, and assigns a
port address. The Auto setting will detect and available address.
Parallel Port Mode (ECP)
This item decides the parallel port mode. You can select SPP (Standard Paral-
lel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or
ECP + EPP.
Parallel Port IRQ (7)
This item assigns either IRQ 5 or 7 to the parallel port.
Parallel Port DMA (3)
This item assigns a DMA channel to the parallel port. The options are 0, 1 and
3.
OnBoard Game Port (201h)
This item enables or disables the I/O address for the game port.
OnBoard MIDI Port/IRQ (300h)
This item enables or disables the onboard MIDI port, and assigns a port ad-
dress.
MIDI Port IRQ (10)
This item assigns IRQ 5 to the parallel port.
OnBoard IDE (Both)
This item enables or disables either or both of the onboard Primary and Sec-
ondary IDE channels.
Ethernet Device (Enabled)
This item enables or disables the onboard Ethernet LAN.
Audio Device (Enabled)
This item enables or disables the onboard AC’97 audio chip.
Modem Device (Auto)
This item enables or disables the onboard AC’97 modem chip.
USB Controller (Enabled)
Enable this item to select the USB ports or disable.
USB Device Legacy Support (Disabled)
This item enables the USB device, if you have installed a USB device on the
system board.
ThumbDrive Support for DOS (Disable)
Enable this item to make a small portion of memory storage device for the
USB ports.
