Keyboard Power On /Wake up key/Wake up password
(Disabled/Any Key/NA)
If you enable this item, system can automatically resume by pressing hot keys
on the keyboard or typing in the password. You must enable the Keyboard
Power On jumper and use an ATX power supply in order to use this feature.
PowerOn by RTC Alarm / Date / Hour / Minute / Second
(Disabled/15/12/30/30)
The system can be turned off with a software command. If you enable this
item, the system can automatically resume at a fixed time based on the sys-
tem’s RTC (realtime clock). Use the items below this one to set the date and
time of the wake-up alarm. You must use an ATX power supply in order to use
this feature.
PCI / Plug and Play Setup
This page sets some of the parameters for devices installed on the PCI bus
and devices that use the system plug and play capability.
AMIBIOS SETUP – PCI / PLUG AND PLAY SETUP
(C) 2000 American Megatrends, Inc. All Rights Reserved
Plug and Play Aware O/S Yes
Share Memory Size 32MB
Primary Graphics Adapter PCI
Allocate IRQ for PCI VGA Yes
PCI IDE BusMaster Disabled
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
Plug and Play Aware O/S (Yes)
Enable this item if you are using an O/S that supports Plug and Play such as
Windows 95 or 98.
Share Memory Size (32MB)
This item lets you allocate a portion of the main memory for the onboard VGA
display application with 8/16/32MB options.
Primary Graphics Adapter (PCI)
This item indicates if the primary graphics adapter uses the PCI or the AGP
bus. The default PCI setting still lets the onboard display work and allows the
use of a second display card installed in a PCI slot.
Allocate IRQ for PCI VGA (Yes)
If this item is enabled, an IRQ will be assigned to the PCI VGA graphics sys-
tem. You set this value to No to free up an IRQ.
PCI IDE BusMaster (Disabled)
This item enables or disables the DMA under DOS mode. We recommend you
31
