ATX1: ATX 20-pin Power Connector
Pin Signal Name Pin Signal Name
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PS ON#
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PWRGD 18 +5V
9 +5VSB 19 +5V
10 +12V 20 +5V
SPK1: Internal speaker
Pin Signal Name
1 +5V
2 NC
3 GND
4 SPKR
J1: Onboard LAN LED Connector
Pins 1-2 are for Link LED. Pins 3-4 are for 10/100 Mbps mode LED, the on-
board LAN run in 100 Mbps mode when the LED lit.
Pin Signal Name
1 Link LED
2 LED+
3 LED+
4 10/100 Mbps mode LED
