Built-in Ethernet
LAN (optional)
• Built-in 10BaseT/100BaseTX Ethernet LAN
• LAN controller integrates Fast Ethernet MAC and PHY
compliant with IEEE802.3u 100BASE-TX, 10BASE-T and
ANSI X3.263 TP-PMD standards
• Compliant with ACPI 1.0 and the Network Device Class
Power Management 1.1
• High Performance provided by 100Mbps clock generator
and data recovery circuit for 100Mbps receiver
Onboard I/O
Ports
• Provides PC99 Color Connectors for easy peripheral
device connections
• Floppy disk drive connector with 1Mb/s transfer rate
• Two PS/2 ports for keyboard and mouse
• One serial port with 16C550-compatible fast UART
• One parallel port with ECP and EPP support
• One MIDI/Game port
• Two back-panel USB ports and extra four USB ports
(onboard USB headers: header USB2 and USB3)— all
support USB2.0
• One infrared port connector for optional module
USB 2.0
• Compliant with Universal Serial Bus Specification Revi-
sion 2.0
• Compliant with Intel’s Enhanced Host Controller
Interface Specification Revision 0.95
• Compliant with Universal Host Controller Interface
Specification Revision 1.1
• PCI multi-function device consists of two UHCI Host
Controller cores for full-/low-speed signaling and one
EHCI Host Controller core for high-speed signaling
• Root hub consists 4 downstream facing ports with
integrated physical layer transceivers shared by UHCI
and EHCI Host Controller
• Support PCI-Bus Power Management Interface
Specification release 1.1
• Legacy support for all downstream facing ports
Hardware Moni-
toring
Built-in hardware monitoring for CPU & System temperatures,
fan speeds and mainboard voltages.
Onboard Flash
ROM
Supports Plug and Play configuration of peripheral devices
and expansion cards.
3
