ECS LIVA X User Manual

LIVA X MINI PC USER MANUAL
3
Chapter 1
• 1 x DC_IN port (12V only)
• 1 x HDMI port
• 1 x RJ45 LAN connector
• 1 x Audio combo jack
• 1 x VGA port
Rear Panel I/O
LAN
• Realtek RTL8111G-CG Gigabit LAN
- 10/100/1000 Fast Ethernet Controller
• Realtek ALC283
- 2 Channel High Definition Audio Codec
- 3.5 mm jack with stereo sound and mic
(combo) supports for jack detection
Audio
• 1 x 2-pin battery connector
• 2 x mini PCIE slots
• 1 x power button
• 1 x System LED header
• 1 x UART Debug header
Internal I/O
Connectors &
Headers
• AMI BIOS with 64Mb SPI Flash ROM
• Support dual display (depends on display
output)
System BIOS
Power Adapter
-12V/ 3A/ 36W DC Adapter
OS Support • Windows 7*/Windows 8.1
*Note: Windows 7 is only supported by mSATA
Dimension
• 135 x 83 x 40mm
storage device.
• APD WA-36A12
• Windows 8.1 with Bing pre-loaded*
*Note: OS pre-installation is subject to certain
product.

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
