ECS LIVA X User Manual

30
LIVA X MINI PC USER MANUAL
Chapter 2
This page enables you to set the clock speed and system bus for
your system. The clock speed and system bus are determined by
the kind of processor you have installed in your system.
Tweak Menu
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Tweak
CPU Frequency 83.3 MHz
CPU Ratio 19
Intel(R) Celeron(R) CPU N2808 @ 1.58GHz
CPU Speed 1.58 GHz
Memory Frequency 1333 MHz
Total Memory 4096 MB (LPDDR3)
CPU Frequency (83.3 MHz)
This item shows the imformation of the CPU frequency.
CPU Ratio (19)
This item shows the information of the CPU Ratio.
Intel(R) Celeron(R) CPU N2808 @ 1.58GHz
This is display-only field and diaplays the information of the CPU
installed in your computer.
CPU Speed (1.58 GHz)
This item shows the processor speed.
Memory Frequency (1333 MHz)
This item shows the memory frequency.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Chipset Tweak Boot Security Exit

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
