ECS LIVA X User Manual

36
LIVA X MINI PC USER MANUAL
Chapter 2
This page enables you to set the keyboard Numlock State.
Exit Menu
Save Changes and Exit
This item enables you to exit the system setup after saving the
changes.
Discard Changes and Exit
This item enables you to exit the system setup without saving any
changes.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Exit system setup after
saving the changes.
Save Changes and Exit
Discard Changes and Exit
Save Changes and Reset
Discard changes and Reset
Save Options
Save Changes
Discard Changes
Restore Defaults
Save as User Defaults
Restore User Defaults
Boot Override
Windows Boot Manager
UEFI: JetFlashTS4GJFV20 0.00(FAT32)
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Save Changes and Reset
This item enables you to reset the system setup after saving the
changes.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Chipset Tweak Boot Security Exit

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
