ECS LIVA X User Manual

2
LIVA X MINI PC USER MANUAL
Chapter 1
CPU/Chipset
• 4GB/2GB DDR3L
- Single channel DDR3L soldered down
memory
Memory
• 1 x mini PCIE slot
• 1 x mSATA slot
(one supports half-card for wireless card, the
other supports full-card for mSATA SSD)
• Direct soldered down eMMC 32/64GB
• Additional storage from mSATA SSD and
USB flash drive
Expansion
Storage
•Intel
®
Bay Trail-M SoC
Specifications
Note:
ID design and specification may vary, please refer
to actual goods you purchase.
Slots

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
