ECS LIVA X User Manual

LIVA X MINI PC USER MANUAL
11
Chapter 2
Resetting the Default CMOS Values
When powering on for the first time, the POST screen may show a
“CMOS Settings Wrong” message. This standard message will appear
following a clear CMOS data at factory by the manufacturer. You
simply need to Load Default Settings and Save it to reset the default
CMOS values.
Note: Changes to system hardware such as different CPU, memories,
etc. may also trigger this message.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Choose the system
default language
BIOS Information
System Language [English]
System Date [Tue 10/28/2014]
System Time [11:16:31]
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Chipset Tweak Boot Security Exit

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
