ECS LIVA X User Manual

12
LIVA X MINI PC USER MANUAL
Chapter 2
Using BIOS
When you start the Setup Utility, the main menu appears. The main
menu of the Setup Utility displays a list of the options that are
available. A highlight indicates which option is currently selected.
Use the cursor arrow keys to move the highlight to other options.
When an option is highlighted, execute the option by pressing
<Enter>.
Some options lead to pop-up dialog boxes that prompt you to verify
that you wish to execute that option. Other options lead to dialog
boxes that prompt you for information.
Some options (marked with a triangle


) lead to submenus that
enable you to change the values for the option. Use the cursor
arrow keys to scroll through the items in the submenu.
The default BIOS setting for this motherboard apply for most
conditions with optimum performance. We do not suggest
users change the default values in the BIOS setup and take
no responsibility to any damage caused by changing the
BIOS settings.
In this manual, default values are enclosed in parenthesis. Submenu
items are denoted by a triangle


.

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
