ECS LIVA X User Manual

26
LIVA X MINI PC USER MANUAL
Chapter 2
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
USB Configuration
Use this item to show the information of USB configuration.

USB Configuration
All USB Devices [Enabled]
Legacy USB Support [Enabled]
XHCI Mode [Enabled]
USB Support
Parameters
All USB Devices (Enabled)
Use this item to enable or disable all USB devices.
XHCI Mode (Enabled)
Use this item to enable or disable USB XHCI mode.
Press <Esc> to return to the Advanced Menu page.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices.

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
