ECS LIVA X User Manual

LIVA X MINI PC USER MANUAL
39
Chapter 3
Installing the Windows OS
There are two ways to install the Windows OS:
1. Install Windows OS via Windows official DVD.
2. Install Windows OS via USB flash drive.
a) Create an ISO file from the Windows 8.1 DVD.
b) Download the Windows 7 USB/DVD Download Tool from
Microsoft and install it. Please refer to the link:
This free program from Microsoft properly formats your flash drive
and then copies the contents of the Windows 8.1 installation ISO
file to the flash drive.
h t tp://ww w.microsofts t ore.com/s t ore/msusa/html/
pbPage.Help_Win7_usbdvd_dwnTool.
c) Boot from the USB device that you just created to start the
Windows 8.1 installing process.
You need to change the booting priority in BIOS in order to
boot from USB device. Enter into BIOS and select the Boot
in menu (or press the hotkey F7), set USB drive as the first
booting priority.
Chapter 3
Using the Motherboard Software

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
