ECS LIVA X User Manual

LIVA X MINI PC USER MANUAL
35
Chapter 2
Scroll to this item and press <Enter> and view the following screen:
Secure Boot menu

:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Security
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Secure Boot can be
enabled if
1. System running in
User mode with
enrolled Platform
Key(PK)
2. CSM function is
disabled
System Mode Setup
Secure Boot Not Active
Secure Boot [Enabled]
Secure Boot Mode [Standard]
System Mode (User)
This item shows system of secure boot (can be setup or user).
Secure Boot (Active/Enabled)
This item shows the active state of secure boot.
Secure Boot Mode (Standard)
This item is used to select secure boot mode, when you select
standard mode, secure boot policy is fixed; when you select custom
mode, the image execution policy and secure boot key databases
are changeable.

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
