ECS LIVA X User Manual

22
LIVA X MINI PC USER MANUAL
Chapter 2
Socket 0 CPU Information
Scroll to this item and press <Enter> and view the following screen:

:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Socket 0 CPU Information
Intel(R) Celeron(R) CPU N2808 @ 1.58GHz
CPU Signature 30678
Microcode Patch 815
Max CPU Speed 1584 MHz
Min CPU Speed 500 MHz
Processor Cores 2
Intel HT Technology Not Supported
Intel VT-x Technology Supported
L1 Data Cache 24 KB x 2
L1 Code Cache 32 KB x 2
L2 Cache 1024 KB x 1
L3 Cache Not Present
Intel(R) Celeron(R) CPU N2808 @ 1.58GHz
This is display-only field and diaplays the information of the CPU
installed in your computer.
CPU Signature (30678)
This item shows the information of the CPU signature.
Microcode Patch (815)
This item shows the version of microcode patch.
Max CPU Speed (1584 MHz)
This item shows the max speed of the CPU.
Advanced
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.

ECS LIVA X Specifications

General

Processor family	-
Processor frequency	- GHz
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	- GB
Discrete graphics card model	Not available
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Audio chip	Realtek ALC283
Product type	Mini PC
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Chassis type	Small Desktop
Product color	Black
Placement supported	Horizontal/Vertical
Panel mounting interface	75 x 75, 100 x 100 mm
Power supply input voltage	100-240 V

Weight and Dimensions

Depth	83 mm
Width	135 mm
Height	40 mm
Weight	- g
