connectors USB2 to connect the front-mounted ports to the
mainboard.
Pin Signal Pin Signal
1 VERG_FP_USBPWR0 2 VERG_FP_USBPWR0
3 USB_FP_P0- 4 USB_FP_P1-
5 USB_FP_P0+ 6 USB_FP_P1+
7 GROUND 8 GROUND
9 KEY 10 USB_FP_OC0
1. Locate the USB2 connector on the mainboard.
2. Plug the bracket cable onto the USB2 connector.
3. Remove a slot cover from one of the expansion slots on the
system chassis. Install an extension bracket in the opening.
Secure the extension bracket to the chassis with a screw.
READER1: USB Card Reader Connector (optional)
This connector is for connecting internal USB card reader. You can
use a card reader to read or transfer files and digital images to your
computer.
Pin Signal
1 VCC
2 USB-
3 USB+
4 GND
5 KEY
The READER1 is shared with one of the USB ports of
the I/O back panel. The USB port is located beside the
VGA port connector. See “I/O Ports” for more
information.
Please check the pin assignment of the cable and the
USB connector on the mainboard. Make sure the pin
assignment will match before plugging in. Any
incorrect usage may cause unexpected damage to
the system. The vendor won’t be responsible for any
incidental or consequential damage arising from the
usage or misusage of the purchased product.
