Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket
Socket for AMD Phenom
TM
processor (socket AM2+)/AMD Athlon
TM
64 X2 Dual-Core/Athlon
TM
64/Sempron
TM
processors
2. CPU_FAN CPU cooling fan connector
3. SYS_FAN System cooling fan connector
4. DDR2_1~2 240-pin DDR2 SDRAM slots
5. ATX_POWER Standard 24-Pin ATX Power connector
6. IDE Primary IDE connector
7. SATA1~6 Serial ATA connectors
8. F_PANEL Front Panel Switch/LED header
9. LPT Onboard parallel port header
10. SPK Speaker header
11. CLR_CMOS Clear CMOS jumper
12. USBPWR_F1 Front Panel USB Power Select Jumper
13. F_USB1~2 Front Panel USB headers
14. SPDIFO SPDIF out header
15. CD_IN Analog audio input connector
16. F_AUDIO Front Panel Audio header
17. PCI1~2 32-bit add-on card slots
18. PCIEX1 PCI Express x1 slot
19. IR Infrared header
20. PCIEX16 PCI Express x16 graphics card slot
21. USBPWR_R1 Rear Panel USB PS/2 Power Select Jumper
22. ATX12V 4-pin +12V power connector
