Using BIOS
Standard CMOS Setup
This option displays basic information about your system.
Date & Time
The Date and Time items show the current date and time on the computer. If you are
running a Windows OS, these items are automatically updated whenever you make
changes to the Windows Date and Time Properties utility.
CMOS SETUP UTILITY – Copyright (C) 1985-2007, American Megatrends, Inc.
SATA 1
SATA
LBA/Large Mode
Block (Multi-Sector Transfer Auto
PIO Mode Auto
DMA Mode Auto
S.M.A.R.T Auto
32Bit Data Transfer Enabled
Help Item
Disabled: Disables LBA
Mode.
Auto: Enables LBA
Mode if the device
supports it and the
device is not already
formatted with LBA
Mode disabled.
Device : Not Detected
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Default settings
F1: General Help
Auto
LBA/Large Mode (Auto)
Use this item to set the LAB/Large mode to enhance hard disk performance by
optimizing the area the hard disk is visited each time.
Date Sat 03/22/2008
f
SATA 1 Not Detected
SATA 2 Not Detected
SATA 3 Not Detected
SATA 4 Not Detected
SATA 5 Not Detected
SATA 6 Not Detected
IDE Master Not Detected
IDE Slave Not Detected
Help Item
f
f
f
CMOS Setup Utility -- Copyright (C) 1985-2007, American Megatrends, Inc.
Time 20:44:15
User [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Date.
Standard CMOS Setup
IDE BusMaster Enabled
f
f
f
f
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Default settings
F1: General Help
mn
< >
SATA1~6, IDE Master/Slave
f
Your computer has one IDE channel which can be installed with one or two devices
(Master and Slave). In addition, this motherboard supports six SATA channels and
each channel allows one SATA device to be installed. Use these items to configure
each device on the IDE channel.
