Using BIOS
Share Memory Auto Detection (Enabled)
Disable this item to set the Share Memory Size. And if the item is set to Auto, Share
Memory Size can be controlled according to the dram size. When the dram size is
less than 512 MB, Share Memory Size should be set to 64 MB. While between 512
MB and 1 GB, it should be set to 128 MB. When more than 1 GB, it should be set to
256 MB.
Surround View (Disabled)
ATI Surroundview function only support when using ATI PCIE graphics card.
DCT Unganged View (Enabled)
This item is used to select the DCT mode (DRAM Controller mode).
HDMI Audio (Enabled)
This item is used to enable or disable the NB HDMI audio support.
Press <Esc> to return to the main menu setting page.
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
Onboard SATA Mode Enabled
SATA Configuration IDE
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
OnBoard IR Disabled
Parallel Port Address 378
Parallel Port Mode Normal
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
Help Item
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Default settings
F1: General Help
mn
< >
Onboard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
Onboard SATA Mode (Enabled)
Use this item to enable or disable the build-in on-chip Serial ATA.
SATA Configuration (IDE)
Use this item to select the type of the build-in on-chip Serial ATA
OnBoard AUDIO Function (Enabled)
Use this item to enable or disable the onboard Audio function.
