Chapter 3: BIOS Setup Utility
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility – Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Help Item
Integrated Peripherals Page
Onboard IDE Controller
Onboard SATA Controller
Use this item to enable or disable the onboard IDE interface.
This item allows you to enable or disable the onboard SATA controller.
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F9: Load Default Settings
Onboard IDE Controller Enabled
OnBoard SATA Controller Enhanced
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
DISABLED: disables the
integrated IDE
Controller.
ENABLED: enables both
Controllers.
Onboard LAN Function
Use this item to enable or disable the onboard LAN function.
Onboard LAN Boot ROM
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Serial Port1 Address
Use this item to enable or disable the onboard COM1 serial port, and to assign a
port address.
Parallel Port Address
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
Parallel Port Mode
Use this item to select the parallel port mode. You can select Normal (Standard
Parallel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or
BPP (Bi-Directional Parallel Port).
ECP Mode DMA Channel
Use this item to assign the DMA Channel under ECP Mode function.
Onboard AUDIO Function
Use this item to enable or disable the onboard audio device.
