Motherboard User’s Guide
Advanced Setup Page
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility – Copyright (C) 1985-2005, American Megatrends, Inc.
Advanced Setup
Help Item
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F9: Load Default Settings
For the processor its
CPUID belows 0F14h.
TM2 only can be enable
under below settings.
1.Freq.>=3.6GHz FSB800
2.Freq.>=2.8GHz FSB533
Quick Power On Self Test
Enable this item to shorten the power on self testing (POST) and have your system
start up faster. You might like to enable this item after you confident that your
system hardware is operating smoothly.
Thermal Management Enabled
TM Status TM1/TM2
Limit CPUID MaxVal Disabled
Enhanced Halt (C1E) Enabled
Intel XD Bit Disabled
Intel EIST Enabled
Quick Power on Self T
est Enabled
Boot Up Numlock Status On
APIC Mode Enabled
1st Boot Device Hard Drive
2nd Boot Device CD/DVD
3rd Boot Device Removable Dev.
Hard Disk Drives Press Enter
CD/DVD Drivers Press Enter
Boot Other Device Yes
Thermal Management
This item displays CPU’s temperature and enables you to set a safe temperature
to Prescott CPU.
Enhanced Halt (C1E)
This item enables or disables enhanced halt (C1E).
Intel XD Bit
This item allows users to enable or disable the Intel XD bit.
Intel EIST
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep
technology).
TM Status
This item displays CPU Monitor status.
Limit CPUID MaxVal (Disabled)
Use this item to enable or disable the Max CPU ID value limit. When supports
Prescott and LGA775 CPUs, enables this to prevent the system from “rebooting”
when trying to install Windows NT 4.0.
f
f
Boot Up NumLock Status
This item determines if the NumLock key is active or inactive at system start-up
time.
To Next Page
