Introducing the Motherboard

Table of Motherboard Components

This concludes Chapter 1. The next chapter explains how to install the motherboard.

LABEL COMPONENTS

LGA1155 socket for 2

Generation Intel

Core

Family &

Unlock processors

2. CPU_FAN CPU cooling fan connector

3. DDR3_1~4 240-pin DDR3 SDRAM slots

4. CASE_FAN Case cooling fan connector

5. ATX_POWER Standard 24-pin ATX power connector

6. SYS_FAN System cooling fan connector

7. SATA1~6 Serial ATA connectors (SATA1~2 support SATA 6Gb/s)

8. SPI_DEBUG SPI debug header-for factory use only

9. ME_UNLOCK ME unlock header-for factory use only

10. F_PANEL Front panel switch/LED header

11. USB3F Front panel USB 3.0 header (USB 3F supports EZ Charger)

12. CLR_CMOS Clear CMOS j umper

13. F_USB1~3 Front panel USB header (F_USB1 supports EZ Charger)

14. COM Onboard serial port header

15. PWR_BTN Power on button

16. RST_BTN Reset button

17. PWR_FAN Power cooling fan connector

18. SPDIFO SPDIF out header

19. F_AUDIO Front panel audio header

20. PCI1~2 32-bit add-on card slot

21. PCIE16X1~2 PCI Express x16 slot for graphics interface

22. PCIE PCI Express x1 slot

23. ATX12V 8-pin +12V power connector

1. CPU Socket

Questions and Answers:

Need help?

Do you have a question about the ECS P67H2-A2 and is the answer not in the manual?

ECS P67H2-A2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7 32 bit/64 bit
PCI Express slots version	2.0
On-board graphics card	No
RAID levels	0, 1, 5, 10
LAN controller	RealTek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	-
BIOS memory size	32 Mbit
