PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paeameters for critical voltages, temperatures and fan speeds.
-=- PECI Mode -=-
Offset to TCC Activation Temp : -27
+/- : Change Opt.
Enter : Select
:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
System Temperature : 27°C
CPU Fan Speed : 2947 RPM
System Fan Speed : 0 RPM
CPU Vcore : 1.188V
IMC Voltage : 1.044V
DIMM Voltage : 1.488V
PCH Voltage : 1.056V
CPU SA Voltage : 0.924V
+12V : 11.952V
VCC 5V : 5.088V
VBAT : 3.336V
Smart Fan Function
ESC:Exit
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -39
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
CPU Smart FAN Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
Version 2.02.1205. Copyright (C) 2012, American Megatrends, Inc.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(-) 30
Delta T +3
Smart Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (-) 23
System SMART FAN Control [Enabled]
Smart Fan Mode [Normal]
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(-) 30
Delta T +3
Smart Fan Slope PWM value 10 PWM value/unite
System Fan Full Speed Offset (-) 23
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
