Intel

Matrix Storage Manager RAID Configurations

2. When the RAID Level item is highlighted, use the up/down arrow key to

select the RAID set that you want to create.

Creating a RAID set

1. In the main Intel

Matrix Storage Manager RAID BIOS menu, highlight

Create RAID Volume using the up/down arrow key then press <Enter>.

3. Key in the RAID volume capacity. Use the up/down arrow to choose the

Capacity. The default value indicates the maximum capacity using the

selected disks. Entering a lower capacity allows you to create a second

volume on these disks.

When more than two HDDs are installed in your computer, the Disks item

will be selectable. Then users can select the HDD that you want to belong

to the RAID set. Please be noticed that selecting a wrong disk will result in

losing the original data of the HDD.

Questions and Answers:

Need help?

Do you have a question about the ECS P67H2-A2 and is the answer not in the manual?

ECS P67H2-A2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7 32 bit/64 bit
PCI Express slots version	2.0
On-board graphics card	No
RAID levels	0, 1, 5, 10
LAN controller	RealTek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	-
BIOS memory size	32 Mbit
