Installing the Motherboard

Installing Memory Modules

This motherboard accommodates four memory modules. It can support four 240-pin

DDR3 DDR3 2133 (OC)/DDR3 1866 (OC)/1600 (OC)/1333/1066 SDRAM. The

total memory capacity is 16 GB.

You must install at least one module in any of the four slots. Total memory capacity

is 16 GB.

Channel A: DDR3_1, DDR3_2

Channel B: DDR3_3, DDR3_4

The four DDR3 memory sockets (DDR3_1, DDR3_2, DDR3_3 and DDR3_4) are

divided into two channels and each channel has two memory sockets as following:

1. To achieve better airflow rates and heat dissipation, we suggest that

you use a high quality fan with 3800 rpm at least. CPU fan and

heatsink installation procedures may vary with the type of CPU fan/

heatsink supplied. The form and size of fan/heatsink may also vary.

2. DO NOT remove the CPU cap from the socket before installing a

CPU.

3. Return Material Authorization (RMA) requests will be accepted

only if the motherboard comes with the cap on the LGA1155 socket.

Recommend memory configuration

DDR3_1 DDR3_2 DDR3_3 DDR3_4

1 DIMM -- Populated -- --

1 DIMM -- -- -- Populated

2 DIMMs -- Populated -- Populated

3 DIMMs Populated Populated -- Populated

3 DIMMs -- Populated Populated Populated

4 DIMMs Populated Populated Populated Populated

Mode

Sockets

Questions and Answers:

Need help?

Do you have a question about the ECS P67H2-A2 and is the answer not in the manual?

ECS P67H2-A2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7 32 bit/64 bit
PCI Express slots version	2.0
On-board graphics card	No
RAID levels	0, 1, 5, 10
LAN controller	RealTek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	-
BIOS memory size	32 Mbit
