Using BIOS

SMART Fan start PWM value (180)

SMART Fan start TEMP(-) (30)

This item is used to set the start PWM value of the smart fan.

This item is used to set the start temperature of the smart fan.

DeltaT (+3)

This item specifies the range that controls CPU temperature and keeps it from going

so high or so low when smart fan works.

SMART Fan Slope PWM value (10 PWM value/unite)

This item is used to set the Slope Select PWM of the smart fan.

This item is used to set the CPU fan full speed offset value.

CPU Fan Full Speed Offset(-) (23)

Smart Fan Mode (Normal)

This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a

better operation environment. If you choose Normal mode, the fan speed will be auto

adjusted depending on the CPU temperature. If you choose Quite mode, the fan speed

will be auto minimized for quiet environment. If you choose Silent mode, the fan

speed will be auto restricted to make system more quietly. If you choose Manual

mode, the fan speed will be adjust depending on users’ parameters.

This item is used to set the system fan full speed offset value.

System Fan Full Speed Offset(-) (23)

Press <Esc> to return to the PC Health Status page.

• CPU Vcore

• IMC Voltage

• VDIMM

• PCH Voltage

System Component Characteristics

These items display the monitoring of the overall inboard hardware health

events, such as System & CPU temperature, CPU & DIMM voltage, CPU &

system fan speed,... etc.

Press <Esc> to return to the Advanced Menu page.

Questions and Answers:

Need help?

Do you have a question about the ECS P67H2-A2 and is the answer not in the manual?

ECS P67H2-A2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7 32 bit/64 bit
PCI Express slots version	2.0
On-board graphics card	No
RAID levels	0, 1, 5, 10
LAN controller	RealTek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	-
BIOS memory size	32 Mbit
