ECS P67H2-A2 User Manual

17
Installing the Motherboard
USB3F: Front Panel USB 3.0 headers.
This Motherboard implements one USB 3.0 header supporting 2 extra front USB 3.0
ports, which delivers 5Gb/s transfer rate. USB3F supports EZ Charger technology,
provides about 1A current than general USB port in off mode for USB devices. It is
useful and excellent, especially for the iPhone, iPad and iPod touch devices that need
a large amount of current for faster recharging within less time.
1 Vbus Front Panel USB Power
2 IntA_P1_SSRX- USB3 ICC Port1 SuperSpeed Rx-
3 IntA_P2_SSRX+ USB3 ICC Port1 SuperSpeed Rx+
4 GND GND
5 IntA_P1_SSTX- USB3 ICC Port1 SuperSpeed Tx-
6 IntA_P1_SSTX+ USB3 ICC Port1 SuperSpeed Tx+
7 GND GND
8 IntA_P1_D- USB3 ICC Port1 D-
9 IntA_P1_D+ USB3 ICC Port1 D+
10 ID USBOC- Over Current Protection
Pin Signal Name Function
11 IntA_P2_D+ USB3 ICC Port2 D+
12 IntA_P2_D- USB3 ICC Port2 D-
13 GND GND
Please make sure that the USB cable has the same pin assignment as
indicated above. A different pin assignment may cause damage or system
hang-up.
15 IntA_P2_SSTX- USB3 ICC Port2 SuperSpeed Tx-
16 GND GND
17 IntA_P2_SSRX+ USB3 ICC Port2 SuperSpeed Rx+
18 IntA_P2_SSRX- USB3 ICC Port2 SuperSpeed Rx-
19 Vbus Front Panel USB Power
14 IntA_P2_SSTX+ USB3 ICC Port2 SuperSpeed Tx+
ME_UNLOCK: ME Unlock Header
Short Unlock
Open Lock
Pin 1-2 Function
It is suggested that USB Keyboard and USB Mouse connect to USB 2.0 ports rather
than USB 3.0 ports. Wake up function from S1/S3 may not be supported by those
devices that connect to USB 3.0 ports. USB devices connected to USB 3.0 ports may
not be supported in DOS mode.

ECS P67H2-A2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7 32 bit/64 bit
PCI Express slots version	2.0
On-board graphics card	No
RAID levels	0, 1, 5, 10
LAN controller	RealTek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	-
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
