ECS P67H2-A2 User Manual

41
Using BIOS
Azalia HD Audio
Enabled
Disabled
+/- : Change Opt.
Enter : Select


:Select Screen
:Select Item
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
ME Subsystem Help
Intel ME Subsytem Configuration
ME Version 7.0.0.1135
ME Subsystem [Enabled]
Main Advanced Chipset M.I.B III Boot Security Save & Exit
ME Subsystem
Scroll to this item and press <Enter> to view the following screen.
ME Version (7.0.0.1135)
This item shows the ME version.
ME Subsystem (Enabled)
This item allows you to enable or disable ME subsystem.

ECS P67H2-A2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® P67
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7 32 bit/64 bit
PCI Express slots version	2.0
On-board graphics card	No
RAID levels	0, 1, 5, 10
LAN controller	RealTek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	-
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
