11
A
TX1:
A
TX 20-pin
Power Connector
Pin
Signal Name
Pin
Signal Name
1 +3.3V
11
+3.3V
2 +3.3V
12
-12V
3 Ground
13
Ground
4 +5V
14
PS
ON#
5 Ground
15
Ground
6 +5V
16
Groun
d
7 Ground
17
Ground
8 PWRGD
18
-5V
9 +5VSB
19
+5V
10 +12V
20 +5V
A
TX2:
A
TX 12V Pow
er Connector
Pin
Signal Name
1 +12V
2 +12V
3 Ground
4 Ground
14
16
Table of Contents
Default Chapter
2
About the Manual
2
Canadian Department of Communications
2
Declaration of Conformity
2
Table of Contents
3
CHAPTER 1 Introducing the Motherboard
5
Introduction
5
Features
6
Choosing a Computer Case
8
Motherboard Components
9
CHAPTER 2 Installing the Motherboard
11
Safety Precautions
11
Quick Guide
11
Installing the Motherboard in a Case
12
Setting Jumpers
12
Checking Jumper Settings
13
Jumper Settings
13
Connecting Case Components
14
Front Panel Connector
16
Installing Hardware
17
Installing the Processor
17
Cpu Installation Procedure
18
Installing Memory Modules
19
Installation Procedure
20
Installing a Hard Disk Drive/CD-ROM
21
Installing Serial Ata Hard Drives
23
Installing a Floppy Diskette Drive
24
Installing Add-On Cards
25
Connecting Optional Devices
26
Connecting I/O Devices
30
CHAPTER 3 Using BIOS
31
About the Setup Utility
31
The Standard Configuration
31
Entering the Setup Utility
32
Updating the BIOS
33
Using BIOS
33
Standard CMOS Features
34
Advanced BIOS Features
36
Advanced Chipset Features
39
Integrated Peripherals
43
Power Management Setup Option
48
PNP/PCI Configurations
52
PC Health Status
53
Frequency/Voltage Control
53
Load Fail-Safe Defaults Option
55
Load Optimized Defaults Option
55
Set Password
55
Save & Exit Setup Option
56
Exit Without Saving
56
CHAPTER 4 Using the Motherboard Software
57
About the Software CD-ROM
57
Auto-Installing under Windows 98/ME/2000/XP
57
Running Setup
58
Manual Installation
60
Utility Software Reference
60
