f)
: Time length, the duration of the current monitoring.
(2) Trend/Menu Frame
The trend/menu frame occupies most space of the screen. During monitoring and playing back, it
displays trends; during setting, it displays setup menus.
i) Main Interface
The background supports two standards: 30 ~ 240 (American standard) and 50 ~ 210
(International standard).
There are two top horizontal graticules within the FHR trend frame. They make it easier for you
to estimate if the heart rates have exceeded the preset limits. The FHR1 lower and upper limits
determine its range.
The bottom graticule shows the UA baseline.
ii) Setup Menu
The setup menus include: Function menu, Alarm Configuration menu, Fetal Monitor
Configuration menu, Print Configuration menu, Interpartum Configuration menu, Auto
Monitor menu, Date and Time menu and System menu.
In the setup menus, the pane that encircles an item is called the cursor. Press the UP key or
DOWN key to move the cursor to the previous or next item. When it comes to the needed item,
press the CHANNEL key to stop it. This item will be highlighted. This item might have several
options, press the UP key or DOWN key to switch to the previous or next option. When the
required option appears, press the CHANNEL key to confirm the selection. By then the cursor
will turn into the pane and will be able to move among the items again.
If no action is taken in 30 seconds, the system will return to the upper directory.
Press the SETUP key again to enter the next setup menu.
Press the AUTO key to return to the main interface quickly.
(3) Parameter Frame
Parameter frame lies on the right of the trend frame. The monitoring values are displayed here.
