Technical manual C1P2FXBT – V1.7 p 17/28
This menu allows you to adjust the contrast of the display using the “+” and “-” keys.
To exit the menu, press the “V” key.
This menu allows adjustment of the clock.
The display appears as below:
• The fixed cursor indicates the data which you are modifying (in this case, Monday).
• Use the “V” key to move between the data to be configured.
• Use the “+” and “-” keys to modify the data.
This menu allows you to define the communication address (between 1 and 32) using external
software (like SenatorFX or SenatorFX.NET). It also allows you to define the communications
mode (RS485 / MOD-TCPIP) to communicate with EDEN software.
This menu also allows you to force stand-alone mode if your control unit was previously config-
ured by software and you now wish to go back into stand-alone mode.
Here you will find the control unit version and its serial number.
Control unit configuration
Scroll through the different numbers, using the “+” and “-” keys. The “V” key is used to confirm a
parameter. The “C” key cancels the entered parameter.
ADJUSTING MONDAY
11:09 26/07/06
CONTROL UNIT
CONFIGURATION
