This menu comprises:
Select the input to use as well as the type of contact, to
watch for unauthorized entry into the enclosure.
Two successive swipes of a badge through the same reader
not allowed. For this, a valid badge must enter through an
entry reader and exit via an exit reader. (The readers must
therefore be configured in the corresponding menu).
Activate / Deactivate the control unit’s radio input.
Select the anti time back delay (time after which a badge
outside the cycle can re-enter/exit again).
Select the transit delay time (maximum time after which a
badge accepted on reader 1 will not be on reader 2 and vice
versa).
Activate / Deactivate the summer / winter time function.
Defines the reader alert level to be recognised by the control
unit.
Defines the communication protocol to be used for reader 1.
Scroll through the different types of reader, using the (+) and
(-) keys.
The following types of reader are available:
Management of Wiegand protocols (management of the last bits sent
by the reader). The number of bits is configurable between 16 and 32.
Management of Wiegand decimal protocols (management of the last
bits sent by the reader). The number of bits is configurable between
16 and 32.
Choice between 26-bit Wiegand (with or without management of site
code) and 30-bit Wiegand (with or without management of site and
distributor codes).
Management of ABA protocol (management of the last characters
sent by the reader). The number of characters is configurable be-
tween 5 and 8.
Management of a SOLO reader with fingerprint recognition.
Management of a BIOVEIN reader with recognition of the vein net-
work.
UNAUTHORISED ENTRY
INTO ENCLOSURE
ANTI-PASS-BACK
DEACTIVATED
ANTI-TIME-BACK
DEACTIVATED
TRANSIT DELAY
DEACTIVATED
SUMMER/WINTER TIME?
DEACTIVATED
To Next Page
