Same as the previous menu.
For the SOLO and BIOVEIN type reader you must enter its identifier (ID on the product serial
number label and its security level (false acceptance rate) and its sensitivity level (detection of
the presence of a finger on the sensor).
Scroll through the different numbers, using the “+” and “-” keys. The “V” key is used to confirm a
parameter. The “C” key cancels the entered parameter.
This menu comprises:
Allows the definition of reader 1 for entry and exit. By
default the reader is neutral.
Allows indication of the output to be used to control an
opening device.
Allows adjustment of the delay during which the relay will
be activated (between 1 and 255 seconds for pulse or
bistable mode).
Allows definition of the input used for the push button.
Same as the push button but for the door contact.
Profile of the different readers. Each reader can function differently depending on the control
unit’s current alert level. For this you have three configurable profiles (one per alert level), as
follows:
Profile 1:
Reader status (Automatic mode / Maintained open / Main-
tained closed).
Reader free access time range (select here a device time
range).
Profile 2 then 3: identical to profile 1
This menu allows the configuration of reader 2 identical to reader 1.
