Edge-Core ECS4620-28F-2AC Cli Reference Guide

Chapter 8 | Authentication Commands
802.1X Port Authentication
– 291 –
connected the network and the process is handled transparently by the dot1x
client software. Only if re-authentication fails is the port blocked.
◆ The connected client is re-authenticated after the interval specified by the
dot1x timeout re-authperiod command. The default is 3600 seconds.
Example
Console(config)#interface eth 1/2
Console(config-if)#dot1x re-authentication
Console(config-if)#
Related Commands
dot1x timeout re-authperiod (291)
dot1x timeout
quiet-period
This command sets the time that a switch port waits after the maximum request
count (see page 288) has been exceeded before attempting to acquire a new client.
Use the no form to reset the default.
Syntax
dot1x timeout quiet-period seconds
no dot1x timeout quiet-period
seconds - The number of seconds. (Range: 1-65535)
Default
60 seconds
Command Mode
Interface Configuration
Example
Console(config)#interface eth 1/2
Console(config-if)#dot1x timeout quiet-period 350
Console(config-if)#
dot1x timeout
re-authperiod
This command sets the time period after which a connected client must be re-
authenticated. Use the no form of this command to reset the default.
Syntax
dot1x timeout re-authperiod seconds
no dot1x timeout re-authperiod
seconds - The number of seconds. (Range: 1-65535)

Edge-Core ECS4620-28F-2AC Specifications

General

Model	ECS4620-28F-2AC
Ports	28
SFP Ports	24
Power over Ethernet (PoE)	No
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	L2/L3
MAC Address Table Size	16K
VLANs	4K
Weight	3.5 kg
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Type	Switch
10G SFP+ Ports	4
Power Supply	AC: 100~240VAC, 50/60 Hz
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1P, IEEE 802.1D, IEEE 802.1S, IEEE 802.1W
